TOYO KEIKI DCF-12N Insulation Resistance Panel Meter 0-5 MOhm 1mA
$119.99
TOYO KEIKI DCF-12N Insulation Resistance Panel Meter 0-5 MOhm 1mA
Specifications
| Brand | TOYO KEIKI |
| Model | DCF-12N |
| Type | Analog insulation resistance panel meter, receiving instrument (RECEIV INST) |
| Series | CF Series fixed panel meter |
| Measuring Range | 0 - 0.1 - 0.5 - 1 - 2 - 5 MOhm to infinity |
| Unit | MOhm (megohm) |
| Full Scale Current | F.S. 1mA |
| Movement | Permanent magnet moving coil, DC |
| Tolerance | ±1.5% (accuracy class 1.5) |
| Operating Position | Vertical |
| Polarity | Positive terminal marked + |
| Application | For use with Toyo Keiki IS-3 insulation resistance monitor (marked WITH IS-3) |
| Scale Plate Code | Sa-247-2C |
| Dimensions | Front 120 x 100 mm, scale length 100 mm |
| Condition | PRE-OWNED / SECOND HAND |
| REF | ATLS3910 |
