SIEMENS 3TK2803-0BB4 Safety Contactor Combination 24VDC 2NO
$99.99
Skip to product information
SIEMENS 3TK2803-0BB4 Safety Contactor Combination 24VDC 2NO
$99.99
Specifications
| BRAND | Siemens |
| MODEL | 3TK2803 |
| PART NUMBER | 3TK2803-0BB4 |
| TYPE | Contactor safety combination / safety relay with enabling circuit |
| SERIES | 3TK28 |
| SUPPLY VOLTAGE | Us (A1;A2): DC 24V |
| ENABLING CONTACTS | 2S / 2NO (13-14, 23-24) |
| CURRENT RATING | Ie AC-1 = 6A |
| CONTACT RATING AC-15 | 4A at 24V, 4A at 230V, 3A at 400V |
| CONTACT RATING DC-13 | 6A at 24V, 0,5A at 230V |
| MOTOR CAPACITY AC-3 | 0,55 kW at 230V, 1,1 kW at 400V |
| AUXILIARY CONTACT RATING | B300/Q300, 6A / 240V AC general use |
| MAX HP | 120 VAC: 1/4 HP single-phase, 3/4 HP three-phase; 240 VAC: 1/2 HP single-phase, 1 HP three-phase |
| SHORT CIRCUIT RATING | Suitable for use on a circuit capable of delivering not more than 5000 rms symmetrical amperes, 300V max |
| CONDUCTOR RATING | Cu wire 60 °C only |
| INDICATION | ON and READY status indicators |
| REVISION | E01 |
| STANDARD | VDE 0660 T.500 (04.94); IEC 60947-1 (1999) |
| APPROVALS | UL Listed 165 C Ind. Cont. Eq.; CSA; CE; BG-PRUFZERT BIA 964003 |
| COUNTRY OF ORIGIN | Made in Czech Republic |
| CONDITION | PRE-OWNED / SECOND HAND |
| QTY AVAILABLE | 4 |
| REF | NTD005 |
