OPTO 22 DC60S3 Solid State Relay 3A 60VDC
$15.00
Skip to product information
OPTO 22 DC60S3 Solid State Relay 3A 60VDC
$15.00
OPTO 22 DC60S3 Solid State Relay 3A 60VDC
Specifications
| Brand | Opto 22 |
| Model | DC60S3 |
| Part Number | DC60S3 |
| Type | Solid State Relay, DC control / DC output |
| Series | Power Series |
| Control Voltage | 3-32VDC |
| Load Voltage | 60 VDC |
| Load Current | 3 A nominal |
| Switching Method | Transistor output, zero-voltage turn-on and zero-current turn-off |
| Surge Current | 5 A for 1 second |
| Forward Voltage Drop | 1.5 V at 3 A |
| Off-State Leakage | 1 mA maximum |
| Input Impedance | 1,000 ohms |
| Isolation | 4,000 VRMS input to output |
| Turn-On Time | 100 microseconds |
| Turn-Off Time | 750 microseconds |
| Operating Temperature | 40 C to 100 C |
| Approvals | CSA, UL Recognized (UR); CE and RoHS per manufacturer |
| Country Of Origin | Made in USA |
| Condition | PRE-OWNED / SECOND HAND |
| REF | ATLS4427 |
| Category | General Purpose Relays |
