MITSUBISHI AJ65SBTB2N-16R CC-Link Remote Output Unit 16-Point 2A
$50.00
MITSUBISHI AJ65SBTB2N-16R CC-Link Remote Output Unit 16-Point 2A
Specifications
| Brand | Mitsubishi Electric |
| Model | AJ65SBTB2N-16R |
| Part Number | AJ65SBTB2N-16R |
| Type | CC-Link remote relay output unit |
| Series | MELSEC CC-Link |
| Output Points | 16 points |
| Output Rating | OUT 24VDC/240VAC 2A, 8.0A/Common |
| Common Arrangement | 16 points per common, 2-wire |
| Supply Voltage | 24VDC (20.4 to 26.4 V DC, ripple within 5%) |
| Current Consumption | 120mA at 24VDC, all points ON |
| Station Type | Remote I/O station, occupies 1 station |
| Dimensions | 179 mm W x 50 mm H x 40 mm D |
| Weight | 0.35 kg |
| Approvals | c UL us Listed, CE; IND. CONT. EQ. 80M1, CLASS 2 ONLY |
| Country Of Origin | Made in Japan |
| Condition | PRE-OWNED / SECOND HAND |
| REF | ATLS4207 |
