MITSUBISHI AJ65SBTB1-16D CC-Link Remote Input Unit 16 Points 24VDC
$50.00
MITSUBISHI AJ65SBTB1-16D CC-Link Remote Input Unit 16 Points 24VDC
Specifications
| Brand | MITSUBISHI |
| Model | AJ65SBTB1-16D |
| Part Number | AJ65SBTB1-16D |
| Type | INPUT UNIT - CC-Link remote DC input unit |
| Series | MELSEC / CC-Link |
| Input Points | 16 points (X0-XF) |
| Rated Input | IN 24VDC 7mA |
| Supply Voltage | 24VDC 35mA |
| Current Rating | 80mA |
| Common Type | 16 points/common, positive/negative common shared type |
| Response Time | 1.5 ms |
| Occupied Stations | 1 station |
| Network | CC-Link, DA / DB / DG / SLD / FG data link and 24V / 24G power connection |
| Settings | DIP switch for STATION NO. (40 20 10 8 4 2 1) and B RATE (4 2 1) |
| Status Indication | PW, L RUN, L ERR. and X0-XF point LEDs |
| Application | Industrial control equipment, Class 2 supply only |
| Standard / Approvals | UL / cUL IND. CONT. EQ., BS LISTED, CE, KC |
| Drawing Number | BD992C361H02 |
| Country Of Origin | MADE IN JAPAN |
| Condition | PRE-OWNED / SECOND HAND |
| REF | ATLS4203 |
