MITSUBISHI AJ65SBTB1-16D CC-Link Remote Input Unit 16-Point 24VDC
$15.00
Skip to product information
MITSUBISHI AJ65SBTB1-16D CC-Link Remote Input Unit 16-Point 24VDC
$15.00
MITSUBISHI AJ65SBTB1-16D CC-Link Remote Input Unit 16-Point 24VDC
Specifications
| Brand | Mitsubishi Electric |
| Model | AJ65SBTB1-16D |
| Type | CC-Link remote input unit (INPUT UNIT) |
| Series | MELSEC, CC-Link |
| Input Points | 16 points, DC input |
| Input Rating | IN 24VDC 7mA |
| Input Voltage Range | 19.2 to 26.4 V DC, ripple within 5% |
| Supply Voltage | 24VDC 35mA |
| Common Type | Positive / negative shared common, 1-wire |
| Isolation | Photocoupler |
| Response Time | 1.5 ms or less OFF-ON and ON-OFF at 24 V DC |
| Occupied Stations | 1 station |
| Dimensions | 118 mm W x 50 mm H x 40 mm D |
| Weight | 0.18 kg |
| Approvals | cULus Listed, 80M1 Industrial Control Equipment, Class 2 only; CE |
| Country Of Origin | Made in Japan |
| Condition | PRE-OWNED / SECOND HAND |
| REF | ATLS4358 |
