HYUNDAI HOR 1M 750 + HOR 1K 5 Thermal Overload Relay 750A 660V
$498.99
Skip to product information
HYUNDAI HOR 1M 750 + HOR 1K 5 Thermal Overload Relay 750A 660V
$498.99
HYUNDAI HOR 1M 750 + HOR 1K 5 Thermal Overload Relay 750A 660V
Specifications
| Brand | HYUNDAI |
| Model | HOR 1M 750 |
| Part Number | HOR 1M 750 |
| Relay Module | HOR 1K 5 (marked on the plug-on relay unit) |
| Type | Thermal Overload Relay, current transformer operated, three-phase |
| Series | HOR |
| Rated Insulation Voltage | Ui=660V |
| Operational Voltage | 660V, 600VAC max. |
| Motor Current | 450A, 600A or 750A motor |
| Relay Setting | 3A for 450A motor, 4A for 600A motor, 5A for 750A motor |
| Thermal Current | Ith=5A |
| Trip Rating | 120% of dial setting |
| Auxiliary Contacts | 1 NC (95-96) and 1 NO (97-98) |
| Max Fuse | aM 630A max; 1,000A max. fuse |
| Short Circuit Current Rating | 5kA at 600V |
| Relay Module Fuse Coordination | 16A coordination type C, 25A coordination type A |
| Standard | IEC292, BS4941, VDE0660, IEC337-1 |
| Approvals | NEMA B600 |
| Licence | Licenced by Stromberg OY |
| Country Of Origin | Made in Korea |
| Condition | PRE-OWNED / SECOND HAND |
| REF | ATLS4095 |
