EMERSON KJ1501X1-BC3 DeltaV DC/DC System Power Supply 24V 12V 8A
$249.99
Specifications
| BRAND | EMERSON |
| MODEL | 73-610-096 |
| PART NUMBER | KJ1501X1-BC3 |
| ASSEMBLY NUMBER | 12P3935X032 |
| TYPE | System Power Supply (Dual DC/DC) |
| SERIES | DeltaV M-series DC to DC Power Supply |
| APPLICATION | Powers DeltaV controllers and I/O interfaces from 12 or 24 VDC bulk power |
| INPUT POWER RATING | 24 V DC +/- 20%, 6.1A OR 12 V DC -4%/+5%, 14.8A |
| OUTPUT POWER RATING -40 TO 60°C | 12 V DC 8.0A (from 24 V input) OR 12 V DC 13.0A (from 12 V input) |
| OUTPUT POWER RATING 70°C | 12 V DC 6.0A (from 24 V input) OR 12 V DC 10.0A (from 12 V input) |
| AUXILIARY OUTPUTS | 5.1 V DC 2.0A and 3.4 V DC 2.0A, combined output power 10.2 Watts Max. |
| ALARM RELAY CONTACT RATING | 30 V DC 2A OR 250 V AC 2A, normally open; for Class 1 Group 2 ratings see dwg 12P1293 |
| AMBIENT TEMPERATURE | 40 to 70° C |
| HAZARDOUS AREA RATING | FM Approved CL. 1 Div. 2 GP A,B,C,D HAZ. LOC. Temp. Rating T4; Ta=70°C |
| ATEX RATING | II 3G Ex nA nC IIC T4, Certificate no: Nemko 07ATEX3058U |
| APPROVALS | FM Approved, CE, CSA LR109492 |
| REVISION | REV. F |
| WARNING | Do not disconnect in hazardous location |
| DOCUMENTATION | See dwg 12P1293 for installation information; see manual for complete specifications |
| MANUFACTURED BY | Astec International Limited - Philippine Branch, Bagumbayan, Quezon City, Philippines 1110 |
| COUNTRY OF ORIGIN | Made in Philippines |
| CONDITION | PRE-OWNED / SECOND HAND |
| QTY AVAILABLE | 1 |
| REF | NTD059 |
