DSE 9701-005-01 DSE9701 Battery Charger 24V 5A 90-305V
$299.99
Skip to product information
DSE 9701-005-01 DSE9701 Battery Charger 24V 5A 90-305V
$299.99
Specifications
| BRAND | DSE (Deep Sea Electronics) |
| MODEL | DSE9701 |
| PART NUMBER | 9701-005-01 |
| TYPE | Switch-mode battery charger |
| SERIES | DSE9000 Series, vertical 24 volt battery chargers |
| SUPPLY VOLTAGE | 90V-305V (line to neutral) |
| FREQUENCY | 50/60HZ (45 Hz to 65 Hz operating range) |
| OUTPUT VOLTAGE | 24V DC |
| OUTPUT CURRENT | 5AMP (5A DC) |
| CHARGE MODE | VBC - constant current / constant voltage with automatic float return |
| RIPPLE AND NOISE | <1% |
| EFFICIENCY | >80% |
| PROTECTION | Reverse polarity, short circuit, over-voltage and over-current protection |
| APPLICATION | Permanent battery charging for generator sets and light or heavy industrial installations; linkable units to increase current output; charge fail output for remote warning |
| DIMENSIONS | DIN rail mounted 110 mm W x 133 mm H x 48 mm D; chassis mounted 112 mm W x 153 mm H x 48 mm D |
| WEIGHT | 0.4 kg |
| STANDARDS | BS EN 61000-6-2, BS EN 61000-6-4, BS EN 60068 series |
| APPROVALS | CE |
| CONDITION | PRE-OWNED / SECOND HAND |
| QTY AVAILABLE | 1 |
| REF | NTD014 |
