BIHL+WIEDEMANN BWU3274 AS-i 3.0 PROFINET Gateway 30V 9W
$980.99
Skip to product information
BIHL+WIEDEMANN BWU3274 AS-i 3.0 PROFINET Gateway 30V 9W
$980.99
Specifications
| BRAND | Bihl+Wiedemann GmbH |
| MODEL | AS-i 3.0 PROFINET Gateway |
| PART NUMBER | BWU3274 (Art.No) |
| IDENT NO | 16415 |
| TYPE | AS-Interface to PROFINET gateway with integrated Safety Monitor |
| SERIES | ASi-3 Master/Gateways |
| CONFIGURATION | 2 AS-i masters with 1 power supply, duplicate address recognition and AS-i inspector |
| SAFETY FUNCTION | Integrated Safety Monitor, 32 release circuits |
| SAFE INPUTS | 3 x 2 channels safe inputs, expandable to max. 62 x 2 channels |
| SAFE OUTPUTS | 6 electronic safe outputs, expandable to max. 32 safe outputs |
| SAFETY LEVEL | SIL 3, Cat. 4 (PL e) |
| SUPPLY VOLTAGE | AS-i +: 30V, AS-i –: 0V |
| POWER | 9W |
| AS-I CIRCUIT CURRENT | max. 4A per AS-i network |
| FIELDBUS INTERFACE | PROFINET, 2 ports |
| DIAGNOSTIC INTERFACE | RS 232, plus chip card configuration |
| DEGREE OF PROTECTION | IP20 |
| APPLICATION | Integration of two AS-i networks into a PROFINET automation system with safety monitoring |
| STANDARD / APPROVALS | cULus Listed Industrial Control Equipment 1HD8, CE, ASi Safety at Work |
| COUNTRY OF ORIGIN | Germany (Bihl+Wiedemann GmbH, D-68199 Mannheim) |
| YEAR OF CONSTRUCTION | 2016 |
| CONDITION | PRE-OWNED / SECOND HAND |
| QTY AVAILABLE | 1 |
| REF | NTD011 |
Shipping & Handling
Ships worldwide from India via DHL, UPS, or Aramex with full tracking. Items are securely packed and dispatched promptly after payment.
Import duties, taxes, and customs charges (if applicable) are the buyer's responsibility and are not included in the item price or shipping cost.
