BIHL+WIEDEMANN BWU2238 AS-i 3.0 PROFINET Gateway 30V 2-Master
$325.99
Skip to product information
BIHL+WIEDEMANN BWU2238 AS-i 3.0 PROFINET Gateway 30V 2-Master
$325.99
Specifications
| BRAND | Bihl+Wiedemann |
| ART NO | BWU2238 |
| IDENT NO | 16128 |
| TYPE | AS-i 3.0 PROFINET Gateway in Stainless Steel, 2-Master |
| SERIES | AS-Interface Master Gateways |
| PROTOCOL | PROFINET |
| AS-I MASTERS | 2 (ASi-3 masters, 2 ASi networks) |
| SUPPLY VOLTAGE | AS-i +: 30V / AS-i -: 0V |
| POWER CONSUMPTION | 9 W |
| INTERFACE | 10/100 M Baud Ethernet (PROFINET) |
| DIAGNOSTIC INTERFACE | RS 232; diagnostics and configuration via PROFINET or RS232 |
| POWER SUPPLY CONCEPT | 1 power supply for 2 ASi networks, integrated decoupling |
| FUNCTIONS | Duplicate address recognition, ASi fault detector, optional programming in C |
| DEGREE OF PROTECTION | IP20 |
| APPLICATION | For use in Class 2 circuits only |
| APPROVALS | UL Listed Ind.Cont.Eq. 1HD8 (file E227214), CE, AS-Interface certified |
| MANUFACTURER ADDRESS | Bihl+Wiedemann GmbH, Flosswoerthstrasse 41, D-68199 Mannheim, Germany |
| CONDITION | PRE-OWNED / SECOND HAND |
| QTY AVAILABLE | 1 |
| REF | NTD009 |
Shipping & Handling
Ships worldwide from India via DHL, UPS, or Aramex with full tracking. Items are securely packed and dispatched promptly after payment.
Import duties, taxes, and customs charges (if applicable) are the buyer's responsibility and are not included in the item price or shipping cost.
