B&R 8LSA35.DB030S200-3 Servo Motor 400V 2.30Nm
$1,499.99
Skip to product information
B&R 8LSA35.DB030S200-3 Servo Motor 400V 2.30Nm
$1,499.99
Specifications
| BRAND | B&R |
| MODEL | 8LSA35.DB030S200-3 |
| TYPE | Servo and Stepper Motor - three-phase synchronous servo motor |
| SERIES | 8LSA / 8LS-3 synchronous motors |
| REVISION | Rev.C4 |
| NOMINAL VOLTAGE | UN = 400 V |
| DC BUS VOLTAGE | 560 VDC |
| NOMINAL CURRENT | IN = 1,40 A |
| STALL CURRENT | I0 = 1,60 A |
| NOMINAL TORQUE | MN = 2,10 Nm |
| STALL TORQUE | M0 = 2,30 Nm |
| NOMINAL SPEED | NN = 3000 min-1 |
| HOLDING BRAKE | Brake: 4,00 Nm |
| POLE PAIRS | 4 |
| ENCODER | DB indirect 32-line multi-turn, V2, single-cable solution |
| SHAFT | Smooth shaft, without oil seal |
| COOLING | Self-cooling, construction type A; Coolant: none |
| INSULATION CLASS | Class F at 40 C ambient |
| PROTECTION | IP64 |
| CENTERING DIAMETER | 80 mm, j6 fit |
| APPROVALS | CE, cULus Recognized Component E360421 |
| COUNTRY OF ORIGIN | Assembled in Austria |
| CONDITION | PRE-OWNED / SECOND HAND |
| QTY AVAILABLE | 7 |
| REF | NTD029 |
