ABB CA5-31E Auxiliary Contact Block 3NO 1NC 16A 690V
$15.00
Skip to product information
ABB CA5-31E Auxiliary Contact Block 3NO 1NC 16A 690V
$15.00
ABB CA5-31E Auxiliary Contact Block 3NO 1NC 16A 690V
Specifications
| Brand | ABB |
| Model | CA5-31E |
| Part Number | CA5-31E |
| Order Code | 1SBN010040R1031 |
| Type | Instantaneous auxiliary contact block, 4-pole front mounted |
| Series | CA5 |
| Rated Insulation Voltage | Ui = 690 V AC |
| Thermal Current | Ith = 16 A |
| Rated Operational Voltage | Ue 230 / 400 / 500-600 V AC |
| Rated Operational Current | Ie AC-15: 4 A at 230 V, 3 A at 400 V, 2 A at 500-600 V |
| Utilisation Category | AC-15; A600 Q300 |
| Poles | 4 |
| Conductor Size | AWG 18-16 Cu str/sol 60/75 degC |
| Tightening Torque | 7 lb-in / 0.8-1 N.m |
| Application | Front-mounted auxiliary contact block for A45-A110, AE45-AE75, AF45-AF110 and TAE45-TAE75 across-the-line contactors |
| Standards | IEC 60947-5-1 / EN 60947-5-1 |
| Approvals | CE, CCC, UL Listed 94D7 Ind Cont Eq, CSA |
| Country Of Origin | Made in France |
| Condition | PRE-OWNED / SECOND HAND |
| REF | ATLS4258 |
Shipping & Assurance: Ships worldwide via DHL · UPS · Aramex. WhatsApp +91-814-038-5618 · sales@inmateto.com
