A Bradley 1606-XLP25A Power Supply 5-5.5V DC 5A 25W
$86.99
Skip to product information
A Bradley 1606-XLP25A Power Supply 5-5.5V DC 5A 25W
$86.99
A Bradley 1606-XLP25A Power Supply 5-5.5V DC 5A 25W
Specifications
| Brand | Allen-Bradley |
| Model | 1606-XLP |
| Cat No | 1606-XLP25A |
| Type | Switched Mode Power Supply |
| Series | SER A |
| Product Family | Bulletin 1606-XLP Compact Power Supply |
| Input Voltage | AC 100-240V (operational range 85...264V AC) |
| Input Current | 0.5A |
| Frequency | 50-60Hz |
| DC Input | For DC input see instruction manual |
| Output Voltage | DC 5-5.5V adjustable, factory set 5.1V |
| Output Current | 5A |
| Output Power | Pout max 25W |
| Efficiency | Approximately 80% |
| Ripple And Noise | 50 mV max |
| Hold-Up Time | Greater than 19 ms at 100V AC |
| Operating Temperature | 10...+60 deg C |
| Humidity | 5 to 95% relative humidity |
| Protection Degree | IP20 |
| Mtbf | 600,000 hours at 40 deg C (SN 29500) |
| Dimensions | 45 mm W x 75 mm H x 91 mm D |
| Weight | 240 g |
| Approvals | cULus Listed IND.CONT.EQ. 18WM, NEC Class 2 Power Supply, CE, N223, GL Germanischer Lloyd |
| Hazardous Location | Class I Div 2, T4 Groups A, B, C, D |
| Safety | Do not use without Protective Earth; installation by professional personnel only; do not open, risk of electrical shock; read instruction manual |
| Country Of Origin | Made in Czech Republic |
| Condition | PRE-OWNED / SECOND HAND |
| REF | ATLS4364 |
